PHAST Fiber Adapter for Camera Link Full Phrontier's new PHAST series supports the most demanding 10 taps x 8 bit configuration up to 85MHz. vOffers 670MB/s bandwidth vPlugs directly into cameras and framegrabbers without CL cables – saves space and cost vSupports base, medium and full configurations vSends high-speed real time image data up to 250meters over LC duplex fiber cables vSingle 5~24VDC power supply vOEM solutions available Contact us to find out more details. info@phrontier-tech.com
PHIRE Single Fiber Adapter for Camera Link
2x2 Switch, 1 to 2 Splitter and Dual Base/Medium Repeater
The PHIRE-S is an fiber optic adapter for Camera Link base configuration. Using only one fiber, the adapter is capable of extending industrial camera signals for up to 10km. The unique single fiber design saves more space, cost and make it easier for cable management for larger industrial systems.
v Single fiber bi-directional data transmission v SC or LC simplex connector and your choice of multimode or single mode fiber v Fully supports base Camera Link cameras and framegrabbers v Direct plug-in, no electrical Camera Link cable is needed v Broad bandwidth - up to 2.5Gb/s for 24 bit image data at 85MHz pixel clock
First of its kind, CLeverTM 2x2 switch for Camera Link is a multifunctional design. It connects two cameras and two framegrabbers with independently controllable image data path, camera control signals and serial communication. Supporting high speed up to 85MHz, the powerful CLever unit is capable of doing all of the following:
v Switch connections between 2 cameras and 2 framegrabbers v Split images from 1 camera into 2 framegrabbers v Synchronously control 2 cameras from 1 framegrabber v Multiplex images from 2 cameras to 1 framegrabber v Repeat image signals for dual base and medium configurations
High Quality Products Send Camera Image Data As Far As 80KM
PHOX is a fiber optic extension system capable of transmitting images up to 50 km. Just Plug-and-play. Supports all brands of Camera Link cameras and framegrabbers, no programming is needed. Use multimode or single mode fiber cables. Additional GPIO and RS232 ports accommodate devices for external trigger and control. More Info >>>
In a super compact industrial grade metal case, PHIRE is a Camera Link fiber adapter that plugs directly into a Camera Link camera and framegrabber without the need of any copper Camera Link cable. The transparent design enables long haul image transmission for up to 80 km via multimode and single mode fiber cables. More Info >>>
We also carry a large variety of accessories: - Camera Link cables: 0.5m, 1m, 3m, 5m, 10m, standard MDR or mini CL - Fiber optic cables: multimode, single mode, standard or custom length - Fiber optical transceivers: SFF, SFP at 1.25G, 2.5G and 4G, multimode, single mode More Info >>>
Suggested Applications
* Intelligent Traffic Systems (ITS) * Flat Panel Display (FPD) Inspection * Glass Inspection * Metal Sheet Inspection * Printing Inspection * Fiber Optic Rotary Joint Application * Medical Imaging * 3-D Imaging * Scientific Measurement * Cameras in Harsh Environment * Sports Arena (simulation, line call) * Military and Defense Applications * Other Machine Vision Applications
